Product Features
Hexa-core high-performance processor for faster system response;
21.5-inch LCD screen with high-definition display and LED backlight for ultra-low power consumption and longer lifespan;
10-point capacitive touch screen with tempered glass cover ensures touch sensitivity and effectively prevents tampering;
Easy-to-use software for a better shopping experience;
High-efficiency thermal paper receipt printer for seamless human-computer interaction.
High recognition rate: Advanced tag collision handling algorithm for fast reading speed and high efficiency.
Compact design: Easy to install and deploy.
Communication interface: TCP/IP (RS485/422 interface customizable)
Transmitter power: 0dBm to 33dBm, adjustable, factory default: 30dBm
Product Parameters:
| Item |
Specification |
| Processor (CPU) |
Rockchip RK3568 (Cortex-A55 ×4), Quad-core, up to 2.0 GHz |
| GPU |
Integrated GPU with Neural Processing Unit (NPU), up to 1 TOPS |
| Memory (RAM) |
4 GB |
| Storage (Flash) |
32 GB |
| Operating System (OS) |
Android 11 |
| Item |
Specification |
| Operating Frequency |
902.00 MHz – 928.00 MHz |
| Antenna Mode |
External antenna |
| Antenna Interface |
SMA ×4 |
| Transmit Power |
0 – 30 dBm |
| Tag Reading Distance |
Up to 50 cm |
| Antenna Boundary Identification Distance |
≤ 8 cm |
| Supported Protocols |
EPCglobal UHF Class 1 Gen2 / ISO 18000-6C |
| Item |
Specification |
| Printing Method |
Thermal line printing |
| Printing Density |
8 dots/mm (576 dots/line) |
| Feeding Direction |
Forward paper feed |
| Printing Speed |
Max. 150 mm/s |
| Paper Width |
72 mm |
| Effective Printing Width |
72 mm |
| Outer Diameter (Roll) |
Max. 80 mm |
| Paper Compartment Width |
80 mm |
| Character Printing |
Western: 12×24 dots, 1.5 mm (W) × 3.0 mm (H) Chinese: GB18030 set, 24×24 dots, 3.0 mm (W) × 3.0 mm (H) |
| Item |
Supported Codes |
| 1D Codes |
UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN/ISSN, Code 39, Code 39 (Full ASCII), Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Codabar, Code 128, UCC/EAN 128 (GS1-128), ISBT 128, Code 93, Code 11, MSI/Plessey, UK/Plessey, China Post, GS1 DataBar series |
| 2D Codes |
PDF417, MicroPDF417, QR Code, Micro QR, DataMatrix, Han Xin Code, Aztec, GS1 Composite |
| Item |
Specification |
| Overall Dimensions (mm) |
700 × 590 × 1720 mm (±5 mm) |
| Packing Material |
Corrugated carton |
| Net Weight |
95 kg |
